HSwitch< T > Class Template Reference

#include <hswitch.h>

Inheritance diagram for HSwitch< T >:

Collaboration diagram for HSwitch< T >:

Classes
struct	ComponentPtr

Public Member Functions
	HSwitch (HWriter< T > *writer, size_t blocksize)
	HSwitch (HWriterConsumer< T > *consumer, size_t blocksize)
	HSwitch (HReader< T > *reader, size_t blocksize)
void	SetWriter (HWriter< T > *writer)
	~HSwitch ()
int	Write (T *src, size_t blocksize)
int	Read (T *dest, size_t blocksize)
void	SetPosition (int position)
int	GetPosition ()
void	Add (HReader< T > *reader)
void	Add (HWriter< T > *writer)
bool	Start ()
bool	Stop ()
bool	Command (HCommand *command)
Public Member Functions inherited from HReader< T >
virtual	~HReader ()=default
HReader< T > *	Reader ()
Public Member Functions inherited from HObject
	HObject ()
Public Member Functions inherited from HWriter< T >
virtual	~HWriter ()=default
HWriter< T > *	Writer ()
Public Member Functions inherited from HWriterConsumer< T >
HWriterConsumer< T > *	Consumer ()

Detailed Description

template<class T>
class HSwitch< T >

Implements a switch that can hold a number of object that can be switched between, say 3 filters where the switch position determines which filter gets the reads or writes passed to/from this component

The switch also has a zero-position called "bypass" (index 0), in which all writes or reads are passed through directly

Allthough you can warp the intended usage pattern by supplying output- or nullwriters , this component is really meant to be used as a pass-through device with filters or other types of sample-manipulating objects.

If you are looking for an on-off switch, use the HMute class.

Constructor & Destructor Documentation

HSwitch() [1/3]

template<class T >

HSwitch< T >::HSwitch	(	HWriter< T > *	writer,
		size_t	blocksize
	)

Construct a new HSwitch that handle writers

HSwitch() [2/3]

template<class T >

HSwitch< T >::HSwitch	(	HWriterConsumer< T > *	consumer,
		size_t	blocksize
	)

Construct a new HSwitch that handle writer consumers

HSwitch() [3/3]

template<class T >

HSwitch< T >::HSwitch	(	HReader< T > *	reader,
		size_t	blocksize
	)

Construct a new HSwitch that handle readers

~HSwitch()

template<class T >

HSwitch< T >::~HSwitch

Default destructor

Member Function Documentation

Add() [1/2]

template<class T >

void HSwitch< T >::Add

(

HReader< T > *

reader

)

Add reader

Add() [2/2]

template<class T >

void HSwitch< T >::Add

(

HWriter< T > *

writer

)

Add writer

Command()

template<class T >

bool HSwitch< T >::Command ( HCommand *  command )

inlinevirtual

Execute or carry through a command

Implements HReader< T >.

GetPosition()

template<class T >

int HSwitch< T >::GetPosition

Get switch position

Read()

template<class T >

int HSwitch< T >::Read ( T *  dest, size_t  blocksize  )

virtual

Read a block of samples

Implements HReader< T >.

SetPosition()

template<class T >

void HSwitch< T >::SetPosition

(

int

position

)

Set switch position

SetWriter()

template<class T >

void HSwitch< T >::SetWriter ( HWriter< T > *  writer )

virtual

Implements HWriterConsumer::SetWriter()

Implements HWriterConsumer< T >.

Start()

template<class T >

bool HSwitch< T >::Start

virtual

Call Start() on all known components

Reimplemented from HReader< T >.

Stop()

template<class T >

bool HSwitch< T >::Stop

virtual

Call Stop() on all known components

Reimplemented from HReader< T >.

Write()

template<class T >

int HSwitch< T >::Write ( T *  src, size_t  blocksize  )

virtual

Write a block of samples

Implements HWriter< T >.

---

The documentation for this class was generated from the following files:

• /home/henrik/Git/Hardt/hardt/libhardt/include/hswitch.h
• /home/henrik/Git/Hardt/hardt/libhardt/components/hswitch.cpp
